Throw-type aerosol fire suppression grenade is an innovative fire extinguishing device, a fireman can put out an initial fire in any small room easily.
Its specifications are as follows:
Product Name
Throwing-type Fire Suppression Grenade
Model Number
AW-THROW100
Overall Dimension
240-millimeter diameter and 110-millimeter height, but handle excluded
Device Weight
5.3 kilograms
Agent quality
2.8 kilograms
Extinguishing application density
56 to 100 grams per cubic meter
protected volume
about 100 cubic meters
start-up time delay
6 to 10 seconds
Operation Manual
Manual
Extinguishing Time
no more than 15 seconds
Color
Red
Life span
10 years
Thermal clearance
When 400℃≤0.14m; When 200℃≤0.28m; When 75℃≤0.75m
Cooling
Reduce temperature from 700℃ to 100℃
Ingress protection performance
IP65
Agent Components
Potassium Nitrate
Working Environment Temperature
Manual screw-in starter with pin
Product Type
Portable and Throwing
Fire Suppress Type
Class A, B, C, E, F
Application
for Firefighters, police officers, trainers, and soldiers.
OEM and labeling service
Available
Throwable fire suppression grenade is designed for special industries, such as the exercise industry, fire rescue industry, and public safety industry, these industries are general practitioners of exercise personnel, firefighters, or public security personnel.
Because it is a special-purpose product, although the market demand is small, we also research and develop it, because we have to be responsible for the development of the industry.
We also have the same special product called the hand-held aerosol fire extinguisher unit, which is for application fields of vehicles, homes, offices, underground pipe galleries, and energy storage containers.
Throw-type aerosol fire suppression grenade is mainly operated by a fireman, and a firefighting department would like to apply it in fire suppression, it has its features:
Green and clean product, environmentally friendly, non-toxic, non-corrosive, ODP is zero, ALT is zero, GWP is zero, it is harmless for the human body and animals.
Without maintenance and no need for yearly inspection.
Easy to operate, just throw it into the fire site to suppress the fire, even a child or an old person can operate it.
Compact, versatile, lightweight, and space-saving, only 5.3 kilograms in weight.
Can be able to suppress fire class A, Class B, Class C, Class E, and Class F.
Portable and no need to approach the ire, when you operate it, just pull out the safety ring and throw it to the fire.
It is even a rescue and evacuation tool.
Very fast to suppress fire, at most 15 seconds the fire will be knocked down.
Its extinguishing volume is 100 cubic meters.
A highly effective clean fire extinguishing agent, with a design density of only 56 grams per cubic meter, it can suppress fire at its initial stages within a few seconds.
Very reliable and safe to use.
It can suppress fire within 30 seconds.
It has a wide range of applications: large document rooms, warehouses, chemical factories, and power stations.
Quick response time, 360-degree annular nozzles, releasing aerosol rapidly to the fire protection zone.
It total-flooded the fire.
It does not have any pressurized cylinders to work.
It is not only suitable for closed spaces but also can be applied in semi-closed spaces.
Portable and mobile, just pull out the safety ring and throw.
Carbon steel cylinders will not easy to get corrosion, without pressure relief, have no leakage, and are low in maintenance.
Pass fire test and inspection, also have certificates to support.
Do not have residue after releasing, and if have it is very easy to sweep up.
Make firefighters to kill fire easier.
It is also a good helper for firefighters and very suitable for the fire fighting department for the government.
This throwing-type aerosol fire extinguishing unit is not only throw-able, but also portable, there is a handle on the side, so people can hold it in their hands, or tie it to a belt.
It is a special design and applies in special fields, for firefighters and firefighting in buildings and other structures.
It can be applied in every stage of fire: early developed fire, fully developed fire.
At present we only have one model of this capacity of throwing type aerosol fire extinguisher:
However, we also have other types of aerosol fire suppression products for you to choose from:
Mini-fixed aerosol units
Portable aerosol units
Wall-mounted aerosol units
Floor-standing aerosol unit
For more Technical Data Sheet, MSDS, Catalogue, and Installation Manual, please feel free to let us know.
